Description

Asiga UltraTM

The Asiga Ultra revolutionizes 3D printing technology with its advanced 4K DLP imaging
technology, enlarged build plate and at the same time a more precise pixel size of only 50
μm, which enables high detail accuracy and surface quality. Equipped with the latest
generation of DLP projectors in the 385nm wavelength range, it adapts seamlessly to a
wide range of applications and supports comprehensive material compatibility. Probably the
most intuitive user interface, complemented by functions such as touchless bonnet
actuation, innovative infrared heating and fast material changeover, make it ideal for any
application. In addition to advanced automation & monitoring capabilities, Asiga’s latest
device also offers a workflow without any calibration. With its compact size of 340 x 440 x
555 mm and a weight of 30.5 kg, the Asiga Ultra combines space efficiency with the
performance of an industrial device.

Dimensions (W x D x H): 340 x 440 x 555 mm
Build volume (X, Y, Z): 192 x 108 x 145 mm
Consistent data formats: STL, SLC, STM
Image technology: 4K DLP imaging with SPSTM technology
Pixel size: 50 μm
Light source: UV LED projector
Wavelength: 385 nm
Voltage source: 100-240 V, 50/60 Hz
Power: 600 W
Weight: 30.5 kg

System requirements:
Processor: 2.4 GHz
Memory: 4 GB
Graphic: 256MB, at least OpenGL 2.0
Mouse: preferred
Network: Supports WiFi, Wireless Direct and Ethernet
Free drive space: 1 GB
